Technical specifications on this page and in the tables on the following two pages are intended only for rough preselection.
Gear teeth: SK (N) 050 – SK(N) 200
                K lingelnberg spiral bevel toothing
Direction of rotation: T he opposite direction when facing C and A
Efficiency: S ize 050 η ~0.95
               S ize 100 η ~0.95
               S ize 200 η ~0.94
Life time: 20000 h
Permissible gearbox temperature at housing: -10 °C to +90 °C
Lubrication: Oil lubrication
Mounting position: Any, please specify when ordering
Surface protection: Primer coat RAL 9005 black
Protection rating: I P 54
